1. This type of fluid coupling is more easy to align, install and dismount.
2. The size of brake pulley could be decided through consultation.
| 型號(hào) Type No. |
A | D | E | F | 充油量Oil filling(L) | 重量(不包括油)Weight w/o oil(kg) | 最高轉(zhuǎn)速M(fèi)ax.speed(r/min) |
過(guò)載系數(shù) Overload ratio |
|
| Max. | Min. | ||||||||
| YOXEZ400 | 329 | Ø480 | 5 | 6 | 9.3 | 4.65 | 120 | 1500 | 2～2.5 |
| YOXEZ420 | 329 | Ø495 | 5 | 6 | 12 | 6 | 140 | 1500 | 2～2.5 |
| YOXEZ450 | 367 | Ø530 | 6 | 6 | 13 | 6.5 | 150 | 1500 | 2～2.5 |
| YOXEZ500 | 367 | Ø590 | 5 | 6 | 19.2 | 9.6 | 160 | 1500 | 2～2.5 |
| YOXEZ510 | 403 | Ø590 | 5 | 6 | 19 | 9.5 | 180 | 1500 | 2～2.5 |
| YOXEZ560 | 438 | Ø650 | 6 | 8 | 27 | 13.5 | 240 | 1500 | 2～2.5 |
| YOXEZ562 | 408 | Ø634 | 5 | 8 | 30 | 15 | 250 | 1500 | 2～2.5 |
| TOXEZ600 | 464 | Ø695 | 6 | 10 | 36 | 18 | 265 | 1500 | 2～2.5 |
| YOXEZ650 | 474 | Ø740 | 5 | 6 | 46 | 23 | 280 | 1500 | 2～2.5 |
| YOXEZ750 | 540 | Ø842 | 6 | 6 | 68 | 34 | 420 | 1500 | 2～2.5 |
| YOXEZ866 | 617 | Ø978 | 7 | 12 | 111 | 55.5 | 660 | 1500 | 2～2.5 |
